The OX-TRAN 2/28 Series of oxygen permeation analyzers with unique 4-cell capability can test four barrier samples at the same time providing twice the throughput of traditional OTR instruments. The new dual film horizontal cartridge is removable for easy sample preparation and the user-friendly operator interface provides real time status of testing against target limits.
Highest Accuracy
- Patented COULOX® sensor is the only absolute Coulometric sensor on the market, never requiring calibration
- Low detection levels down to 0.05 cc/(m2*day)
- Fully automated temperature and flow controls simplify testing and provide unparalleled repeatability
High Throughput
- Industry's fastest sensor response time allows shorter overall test times
- Dual film removable test cartridges allow testing of 4 samples at a time requiring less space
- Automated test method can start a test by a single press of a button
- TruSeal gas flushed perimeter sealing can eliminate the need for absolute zero in many tests thus shortening overall test times
The OX-TRAN 2/28 Series high throughput analyzers can test the Oxygen Transmission Rate (OTR) on films from low to high barriers without humidification. It uses MOCON’s patented COULOX absolute (intrinsic) coulometric sensor requires no calibration and is the base for the ASTM standard D3985. This analyzer provides very accurate and repeatable test results within a wide detection range from 0.05 to 200 cc/(m2*day).
The 4-cell capability allows for triplicate testing with or without a reference film in the same test. The option to run a known standard as a control improves the confidence in the results. With 4 cells and its simplified operation the OX-TRAN 2/28 Series is well-suited for quality control laboratories performing a high volume of OTR tests.
The analyzer has industry leading features such as removable horizontal test cartridges, fully automated testing providing higher throughput in the lab and a QC test mode with real time display of testing status against target limits. It is available with a touch screen operator interface or without one where the control is via a local computer with the same easy to use color graphic interface.
For more than 25 years, MOCON’s OX-TRAN series of instruments have been the most trusted and longest lasting on the market. The OX-TRAN 2/28 Series is the perfect choice for the busy laboratory routinely performing shortened or abbreviated permeation tests.
Removable Cartridges
- Dual film cartridge for double the testing capability
- Easy sample prep on the benchtop
- One button release and loading
- Pneumatic clamping provides more repeatable results
- Extra cartridges can be loaded and staged for testing
TruSeal®
- Eliminate Individual Zero
- Reduced testing time (increase throughput)
- More repeatable results
Automated Control Features
- Store and recall frequently used test methods
- Initiate complete exam cycle with one button
- Flow & Temp control throughout test cycle
- Conditioning mode to increase throughput
- Test report printing and export with pass, fail or warning test results
- Sensor Protection
Simple user interface
- Full color graphic interface shows real time exam status against target limits
- Available with a color touchscreen on the instrument or connect to a PC
- Intuitive automated operation requires less training
- Built in multi-level user management and data security
- Event log & trouble shooting guide
COULOX® Sensor
- Short exam times reduces overall test time to increase throughput
- No sensor calibration required
- Longer sensor life than others on the market
- More accurate and repeatable results vs. sensors that require calibration
- Intrinsic sensor fully complies with ASTM D3985
Warranty
- Full 100% parts and workmanship warranty for 12 months
- Exclusive 4-year warranty on the COULOX sensor
Capabilities - Model-Specific
|
|
Units
|
OX-TRAN 2/28H
|
OX-TRAN 2/28HR
|
|
Test Ranges (50cm2)
|
cc/(m2*day)
|
0.05 to 200
|
0.05 to 200
|
|
cc/(100 in2*day)
|
0.003 to 12.9
|
0.003 to 12.9
|
|
Test Ranges (5cm2)
|
cc/(m2*day)
|
0.5 to 2000
|
0.5 to 2000
|
|
cc/(100 in2*day)
|
0.03 to 129.0
|
0.03 to 129.0
|
|
Resolution (50cm2)
|
cc/(m2*day)
|
0.0001
|
0.0001
|
|
Repeatability
|
cc/(m2*day)
|
0.02 or 1%*
|
0.02 or 1%*
|
|
Test Temperature Range
|
°C
|
20° to 60°C ± 0.2°C
|
20° to 40°C ± 0.2°C
|
|
Controlled RH Testing Range
|
% RH
|
0%
|
0%, 50-90% +/- 5%, test gas only
|
|
Film Size
|
N/A
|
4” x 4” std., 2” x 2” for 5.0 cm2
|
4” x 4” std., 2” x 2” for 5.0 cm2
|
|
Film Thickness
|
N/A
|
Up to 20 Mil for 50 cm2, up to 120 Mil for 5.0 + 10 cm2
|
Up to 20 Mil for 50 cm2, up to 120 Mil for 5.0 + 10 cm2
|
|
Film Test Area
|
N/A
|
50 cm2 std., 10 cm2 + 5.0 cm2 optional
|
50 cm2 std.,10 cm2 + 5.0 cm2 optional
|
*whichever is greater
Other Specifications (all models):
Physical Specifications
- 15.5” H x 12” W x 23” D (39.4 cm x 30.4 cm x 58.0 cm)
- 95 Lbs. (43.1 kg)
Electrical Requirements
- Voltage: 100 - 240 VAC 50/60 Hz
- Maximum Power Draw: 700 VA
Laboratory Requirements
|
Temperature
|
Operation
|
22 °C ± 2 °C
|
|
Storage
|
10 °C to 30 °C
|
|
Humidity
|
Operation
|
20% to 80% RH (non-condensing)
|
|
Storage
|
5% to 85% RH (non-condensing)
|
Gas Supply Requirements
|
Carrier Gas
|
Gas Composition
|
Nitrogen/Hydrogen Mix (98%/2%)
|
|
Supply Pressure, Nominal
|
25 PSI, (1.72 Bar), (172 kPa)
|
|
Test Gas
|
Gas Composition
|
100% Oxygen (purity 99.9%)
|
|
Supply Pressure, Nominal
|
25 PSI, (1.72 Bar), (172 kPa)
|
Connectivity
- Remote Access and Control (requires optional Perm-Net Light software)
- Standard Ethernet port (100T)
- Dual USB 2.0 ports (for connection of keyboard, mouse or memory devices)
Compliance Standards
This product is UL and CSA listed using the ETL mark from Intertek Group plc. and is certified to conform to CE.
Conforms to the following internationally recognized safety standards.
- IEC 61010-1:2010 Third Edition
- UL 61010-1:2012 Third Edition
- CAN/CSA-C22.2 No. 61010-1:2012 Third Edition
Conforms to the following internationally recognized EMC standards.
- EN 61326-1:2013
- EN 61000-3-2:2006, A1:2009, A2:2009
- EN 61000-3-3:2013
Conforms to EU Directive 2011/65/EU RoHS Compliance.
Cartridges & Options
- Extra Dual Film Test Cartridges
Consumables
Software
Service & Support Options
- Basic Preventative Maintenance Plan
- Plus Preventative Maintenance Plan
Packaging Films
- Monolayer
- Multi-layer
- Coated Films
Test Standard Compliance
ASTM D3985
ASTM F2622
ISO CD 15105-2
JIS K-7126-B
DIN 53380-3
GB/T 19789-2005
Test Methodology
Following
ASTM D3985
Standard Test Method for Oxygen Gas Transmission Rate Through Plastic Film and Sheeting Using a Coulometric Sensor
The test specimen is mounted as a semi-barrier between two chambers at ambient atmospheric pressure. One chamber is slowly purged by a stream of nitrogen and the other chamber contains Oxygen. As Oxygen permeates through the film into the nitrogen carrier gas, it is transported to the coulometric detector where it produces an electrical current, the magnitude of which is proportional to the amount of oxygen flowing into the detector per unit of time.
