The Dansensor® CheckMate 4 is our premier headspace gas analyzer – a compact tabletop instrument that combines extreme accuracy and reliability with an intuitive user experience.
You can trust the Dansensor CheckMate 4 to quickly provide accurate and precise measurements – every time – even on packages with extremely limited headspace. For example, the CheckMate 4 SV (model for small volume headspace) ensures accurate oxygen measurements by inserting the probe into the package during testing, instead of withdrawing a sample of gas.
Save test settings for up to 1000 products on the instrument to ensure complete and comparable data records. Quickly switch between product test settings on-screen or by scanning the product’s barcode with the op-tional barcode scanner.
Automated data storage of up to 1,000,000 tests on the instrument ensures accuracy and speed by eliminating the time and risk associated with manual data entry. In addition, data can be transferred via LAN in real time (or via USB drive) to the optional PC software or third-party software. This fast and secure data transfer makes it easy to monitor data across multiple packaging lines and prepare for audits.
This focus on maximizing reliability and uptime is also apparent in the instrument’s unique functional design. The instrument is made up of two components – the control unit and an exchangeable sensor module. This means it is now possible to update the instrument’s sensor module with a newly calibrated module on-site in minutes, eliminating costly and time-consuming service downtime.*
*Service options vary by country. Please speak to your local distributor to see what options are available in your area. For more details, see our Dansensor CheckMate 4 Solution Brochure.
Headspace gas analyzers:
The Dansensor CheckMate 4 is our most accurate and reliable headspace gas analyzer. Dansensor’s headspace gas analyzer portfolio also includes:
- Dansensor® CheckPoint® 4
The Dansensor CheckPoint 4 portable gas analyzer is fast and easy to use. With the highest reliability of any portable headspace analyzer, it provides trusted quality control of MAP.
-
Dansensor® MultiCheck® 2
Dansensor MultiCheck 2 is a reliable all-in-one headspace and leak testing system designed for quality control of MAP packages. Maximize packaging line uptime while protecting your product and brand reputation
-
Dansensor® CheckMate 4 PC Software
Store and evaluate data from one or more CheckMate 4 instruments in this dedicated software option. Simultaneously manage product measurement details and monitor device settings.
-
Dansensor® Can Piercer
The headspace gas of cans and bottles can be analyzed accurately using the Dansensor Can Piercer. The Dansensor Can Piercer tool can be used with either Dansensor CheckPoint 3 or Dansensor CheckMate 4.
Benefits
- Reliable, accurate measurements protect your product and brand
- Increase efficiency with short test times and automated data log-ging
- Easy to use with intuitive touchscreen
- Accurately measure headspace in all sizes of packaging
- Maximize uptime with enhanced hardware and service options
- Reduce errors with defined test programs, automated data han-dling and user logins
Features
- O2 or combined O2/CO2 headspace measurements – flexible con-figuration
- Various applications, including small volume headspace
- Save test settings for quick changes and comparable results
- Data storage and real time data transfer
- Fast and secure LAN connection
- Touchscreen with multilingual graphic interface
- Individual user logins provide security and reduce risk of errors
- Alarm alerts when pre-set gas limits exceeded
- USB port for connecting optional barcode scanner, keyboard or printer
|
Standard applications
|
O2(zirconia)
|
O2(electrochemical)
|
CO2(infrared dual beam)
|
|
Key features
|
Fastest and most accurate oxygen sensor
|
Not sensitive to alcohol, carbon monoxide or carbon dioxide
|
Full-scale, temperature compensated carbon dioxide sensor
|
|
Sample volume (minimum)
|
2 ml
|
5 ml
|
5 ml
|
|
Sample time (minimum)
|
3 sec
|
7 sec
|
8 sec
|
|
Measuring range
|
0-100%
|
0-100%
|
0-100%
|
|
Resolution
|
Under 10% O2: 0.001%
Over 10% O2: 0.01%
|
0.1%
|
0.1%
|
|
Accuracy
|
Under 1%O2: ±0.01%
Over 1%O2: ±1% of readout
|
±0.1%
|
±(0.5% absolute + 1.5% of readout)
|
|
Heating time
|
10 min
|
n/a
|
10 min
|
|
Applications
|
Most food and healthcare applications
|
Packages containing ethanol
(i.e. fresh bread products)
|
Most food and healthcare applications with carbon dioxide
|
|
Calibration and service**
|
12 months
|
6 months
|
12 months
|
|
Small volume applications
|
O2(optical small volume A)
|
O2(optical small volume B)
|
|
|
Key features
|
Accurate in-package oxygen measurement for small headspace
|
Accurate in-package oxygen measurement for small headspace
|
|
|
Sample volume (minimum)
|
No minimum
|
No minimum
|
|
Sample time (minimum)
|
1 sec
|
1 sec
|
|
Measuring range
|
0-50%
|
0-100%
|
|
Resolution
|
Under 10% O2: 0.001%
Over 10% O2: 0.01%
|
Under 10% O2: 0.001%
Over 10% O2: 0.01%
|
|
Accuracy
|
At 1% O2: ±0.05%*
|
At 1% O2:±0.02%*
At 20% O2:±0.2%*
|
|
Heating time
|
n/a
|
n/a
|
|
Applications
|
Small volume packaging like coffee pods, medical vials, ampoules, etc.
|
Blister packages with extremely limited depth and space around the product
|
|
Calibration and service**
|
12 months
|
12 months
|
|
General specifications
|
|
|
|
|
Number of product test settings
|
999
|
|
Data collection capacity
|
Log results of up to 1,000,000 tests
|
|
Data export
|
Stored data to CSV file (USB) or real time data transfer CSV-string per test (RJ-45). Compatible with CheckMate 4 PC software, Microsoft SQL databases and other select third party software.
|
|
Dimensions (WxDxH) and weight
|
305 x 240 x 187mm (12” x 9.4” x 7.4”); 4.2 kg (9.3 lbs)
|
|
Ambient temperature
|
Operational: 0°C to +35°C Storage: -20°C to +60°C
|
|
Relative humidity
|
Operational: 10 to 90 %RH (non-condensing) Storage: less than 95 %RH (non-condensing)
|
|
Power supply and consumption
|
100-240 VAC, 47-63 Hz Max 70W
|
|
Connections
|
LAN: RJ-45 Ethernet 10/100 Mbit/s, DHCP client or fixed IP
USB: 1 x Host, USB 2.0 Type A; 1 x Device, USB 2.0 Type B (max current 500 mA)
|
|
Consumables and accessories
|
Septa, filters, needles, sample hose (kit), CheckMate 4 PC software, SmartPen retractable needle, can piercerfor testing cans and wine bottles***, barcode scanner
|
|
Warranty
|
12 months
|
|
Compliance
|
CE, China RoHS II
|
*At 20°C and 1013 mbar.
** Sensor lifetime depends on usage patterns.
*** Can piercer cannot be used with small volume modules.
Specifications subject to change without notice.
Consumable
- Septa
- Filters
- Needles
- Sample kit
Accessories
- SmartPen – this ergonomic needle improves safety and perfor-mance with retractable needle sheath and replaceable particle fil-ter
- PC software – store and evaluate data from one or more Check-Mate 4 instruments; simultaneously manage product measurement details and monitor device settings
- Can piercer – measure the headspace gas of canned milk powder, wine bottles and similar kinds of containers; connects directly to CheckMate 4
- Barcode scanner – scan the package’s barcode to quickly find the correct test definition
Service & Support Options
This tabletop headspace analyzer is often used directly at the packaging line to quality check that MAP packages contain the correct gas mixture. Use the Manual Spot or Auto Spot measuring modes to test for:
- O2 content
- O2 and CO2 content
It is suitable for a wide variety of food, beverage, pharmaceutical and medical packages that utilize a modified atmosphere, including packages with minimal headspace.
Some examples of our customers’ applications include: Snack Foods - Bakery - Pizza - Meats & Cheese - Nuts - Fish - Fruit, Salads & Vegetables - Pet Foods - Pharmaceutical Packaging - Medical Devices
Alternatively, use the Intermittent measuring mode in the laboratory for testing new package designs and materials and conducting shelf-life studies. The Continuous mode can help you ensure your gas mixer is adjusted correctly and is useful in selected research experiments.
