Multi-Use Package Test Cartridges are designed to test a wide range of package types and ensure accurate, repeatable results.
Standard 80 cm2 Package Test Cartridge - this standard package test cartridge allows a wide range of packages to be tested.
- Uses thin foils with sweep gas hole for package mounting
- Perimeter clamp design holds test foils to the fixture
- Single-use foils eliminate need to remove epoxy from plates
- Truseal® flush ring at perimeter ensures a leak-free seal
Package Adaptor Cartridge - this base cartridge allows testing of complete packages, unique package types and closures. ·
- Vertical fittings for package test configurations
Capture Volume Test Cartridge - these capture volume test chambers are ideal for pre-filled sample testing.
- Stainless steel sanitary clamps for simple set-up
- Range of sizes to fit a wide variety of sample types
- Includes Nylon and Teflon seals for OTR & WVTR testing
- Toolless opening for easy sample insertion and removal
Film Test Cartridge (for package test instrument) - this cartridge allows testing of traditional film or NIST films samples on a package testing instrument or fixture.
- Standard 50 cm2 sample test area
- Incorporates Truseal® to minimize leakage effects
Package Test Chamber - the Test Chamber Cartridge is designed to test empty packages, with a large vertical cylinder chamber for the test gas.
- 80 cm2 base with foils for package mounting
- Inlet valve at bottom and vent at top
- Seal at base for cylinder and refillable water well Applications
- 100% RH test gas conditions Higher than ambient O2 or CO2 test gas
Specialized Package Test Cartridges are specially designed to efficiently test specific types of formed packages, these cartridges incorporate Truseal
® to minimize leakage
Vertical Tray Test Cartridge - this cartridge allows range of larger tray sizes to be tested (up to 8” x 12.5”).
- Uses thin foils with sweep gas hole for package mounting
- Perimeter clamp design holds test foils to the fixture
- Single-use foils eliminates need to scrape and burn off epoxy from plates
- Incorporates Truseal® to minimize leakage
Flexible Pouch Test Cartridge - t
his specially-designed cartridge clamps through test pouches for a clean seal without epoxy.
Carton Test Cartridge - u
se this cartridge to mount a carton without epoxy.
- 1 sided mounting
- Simple cutting tool
- Incorporates Truseal® to minimize leakage
- Reusable fixture reduces cost, reduces sample prep time and improves accuracy
K-Cup Test Cartridge - u
se this cartridge to mount K-cups by flange without using epoxy
- Multi-cup cartridge design allows for any number of K-cups on same cartridge
- Incorporates Truseal® to minimize leakage
- Reusable fixture reduces cost, reduces sample prep time and improves accuracy
PackRack Package Testing Fixture - t
he PackRack expands the testing capability of film permeation analyzers for easy and accurate testing of complete packages
Our package testing cartridges are compatible with package testing permeation analyzers like the OX-TRAN 2/40, OX-TRAN 2/48 and AQUATRAN 3/40. In addition, when used with the PackRack Testing Fixture, they may be used with select film permeation analyzers.
|
Description
|
Part No. (Each)
|
Part No. (Set)
|
|
Standard 80 cm2 Package Test Cartridge
|
052-721
|
054-036 (set of 4)
|
|
Large Vertical Tray Test Cartridge
|
052-703 Right, 052-704 Left
|
054-039 (2 Left & 2 Right)
|
|
Package Test Cartridge for Flexible Pouch
|
052-706
|
054-038 (set of 4 with punch tool)
|
|
Package Adaptor Cartridge
|
052-705
|
054-037 (set of 4)
|
|
Package Test Cartridge for K-Cups: 10
|
054-033
|
054-042 (set of 4)
|
|
Package Test Cartridge - K-Cups: Single
|
054-503
|
N/A
|
|
Film Test Cartridge (for package test instrument)
|
052-737
|
N/A
|
|
Capture Volume Cartridge, 4” x 2”
|
054-591
|
054-592 (set of 4)
|
|
Capture Volume Cartridge, 4” x 12”
|
054-593
|
054-594 (set of 4)
|
|
Capture Volume Cartridge, 6” x 4”
|
054-595
|
054-596 (set of 4)
|
|
Capture Volume Cartridge, 6” x 18”
|
054-597
|
054-598 (set of 4)
|
|
Package Test Chamber
|
054-269 (full assembly), 054-599 (chamber & base)
|
N/A
|
|
Carton Test Cartridge
|
054-534
|
054-536 (set of 4 with cutting tool)
|
|
50 cm2 Film Test Cartridge (for package test instrument)
|
Precise RH: 052-737, 100% RH: 054-271
|
N/A |
|
PackRack
|
054-175
|
N/A
|
